6KE$243007X1A1

About the 6KE$243007X1A1

The General Electric Fuji Electric 6KE$243007X1A1 adjustable frequency drive is part  of the AF-300E$ drive family. The required input voltage is 380-460V and it requires 3 phase power. The 6KE$243007X1A1 is a 7.5 HP drive and it comes with a factory installed keypad. The drive is surrounded in a UL Type 1 enclosure. The amperage is 21.0 and the frequency is 50/60Hz.

The 6KE$243007X1A1 dimensions are 10.24 in. H, 8.66 in. W, and 7.68 in. D. The weight is 14 lbs.

The keypad provides information on output frequency, voltage, current, synchronous speed,  torque, and line (machine speed) information. You can configure the keypad to display in English, Spanish, French or Japanese language. The keypad also provides remote I/O status information and record of previous and current fault conditions.

If the voltage dips briefly during operation (input voltage dips below 310V), the drive can operate for 15 millisec with up to 85% of full voltage.

The drive is configured to sense and record fault conditions such as overcurrent, overvoltage, undervoltage, overheating, motor overload external fault, communication, memory, and microprocessor errors. Indication of the faults are available on the touchpad. The previous 3 faults are retained in memory.

Standard features included in the drive include 3-jump frequencies, restart after instantaneous power failure, slip compensation, switch from line to inverter, multi-speed torque limit control and acceleration/deceleration settings, pattern operation, bias frequency, and energy saving selection.
