6KE1143005X1A1

About the 6KE1143005X1A1

The 6KE1143005X1A1 is a part of the AF-300 E11 from Fuji Electric. The 6KE1143005X1A1 is a 460 VAC, 3 phase device. The drive has five horsepower. The overcurrent is eight point seven (8.7), with an overload of thirteen point one (13.1). The dimensions for this drive are 5.12 (H) x 6.69 (W) x 6.22 (D) and weighs 7.5 pounds. The rated output power (KVA) is 6.9. The rated output rating (KW) is 3.7. The efficiency at 0.75 KHz (%) is 97.4. The efficiency at 15 KHz (%) is 94.9. The watts lost at 0.75 KHz (W) is 116. The watts lost at 15 KHz (W) is 235. The device has a keypad with five small LED lights and six buttons. The LED lights are labeled RUN, Panel Control, Hz, A, and V. The Hz, A, and V lights are collectively labeled PRG. MODE. The Hz and the A light are collectively labeled r.min. The A and the V light are collectively labeled m/min. The buttons have labeled as well and read PRG/RESET, upward arrow (^), RUN (green colored button), FUNC/DATA, downward arrow (˅), and STOP (red colored button). The drive has four metal brackets (one in each corner) to secure the drive into place. The drive has several removable covers to access the inside of the drive if needed. The covers are called an intermediate cover, a control terminal block cover, and a main circuit terminal block terminal. If you would like additional information about this drive please call AX Control.
