6KG1143050X9B1

About the 6KG1143050X9B1

The 6KG1143050X9B1 is a 50 HP Variable Speed drive produced by Fuji Electric. The 6KG1143050X9B1 is featured in the AF-300 G11 series. This drive weighs about seventy-five pounds. The dimensions for this drive are 21.7 (H) x 14.8 (W) x 10.6 (D). The drives overload is one hundred and thirteen (150% for one minute). The rated output current (A) is seventy-five. The NEMA enclosure is open. This drive is a 460 VAC, three phases with a fifty to sixty Hz Input. The Input fuse (L1/R, L2/S, L3/T Nominal) is one hundred and twenty-five. The auxiliary input (RO, TO) is ten. The input circuit breaker (*1) is one hundred and twenty-five. The drive has a digital LED display that shows the output frequency, the setting frequency, the output current, the output voltage, motor synchronous speed, the line speed, the load rotation speed, calculated PID value, PID command value, PID feedback value, and the alarm code. The drive also has a liquid crystal display that shows the operation information, the operation guide, the functional code / name / setting data, alarm information, tester function, motor load rate measuring function (maximum/average current (RMS) during measuring periods, maintenance information) (integrated operation hours, capacitance measurement for main circuit capacitors, heatsink temperature, etc.). This drive supports six languages. For additional information, you can refer to the AF-300 G11 instruction manual. This manual lists detailed information regarding the drive with intricate charts and diagrams.
