6KM$221F50N1A1

About the 6KM$221F50N1A1

The 6KM$221F50N1A1  is a Fuji/GE AF-300 Micro Saver II drive.   This drive is built within a NEMA 1 enclosure and is a single-phase drive rated at 1 HP 240 V.

The 6KM$221F50N1A1 is designed with advanced PWM (pulse width modulation) torque vector control.   This allows control for high starting torque situations.    The unit includes a detachable cover that will allow the user to access wiring points within the drive with ease.

The 6KM$221F50N1A1 includes a front display panel with a place for a four-digit digital display keypad that allows the user to see current, output frequency, voltage, or fault codes.  This keypad was originally optional with NEMA 1 enclosures as sold by the OEM.  The display panel also includes input buttons like a stop and run key, a function key, a program key, and up/down keys.  Additionally, there are three LEDs that function as mode/status indicators.   The keypad is listed in our stock as 6KM$2KP1.

The 6KM$221F50N1A1  is designed for use within indoor locations away from dust, corrosive gases, oil mist, and significant vibration.   The unit should be used only in locations where the relative humidity remains between 20 and 95 percent, noncondensing, and with sufficient clearance from other equipment so as to allow for proper cooling.    The drive cannot be installed upside down or horizontally as this may result in heat build-up that can be dangerous or result in damage to the drive unit.

For more information regarding the specifications or installation procedures of this equipment, please refer to manuals or user guides from Fuji.
