About the 6KM$243001N1A1
The AF-60LP Micro Drive is part of the General Electric’s AF-60 Drive family. The IP20 structure of this drive is open, but a NEMA 1 kit is available for sale and is attachable to the drive. Since this is a micro drive, the power of this device concentrates into a smaller space. The AF-60LP Micro Drive also has a mounting kit that also is for sale. Purchasing this attachment could help organize the work space that this drive resides. This drive comes with many features to improve the experience of the drive. The keypad interface comes with a tuner that the user can manipulate to adjust settings. The dimensions of this device are 6.13 x 2.76 x 6.06 and it weighs 2.43 pounds.The drive also comes with an auto tuner that tunes values with limited user interaction. The device comes with two controllers, a process PI controller and a logic controller. The micro drive also comes with other built-in features. Some of the extra features of the micro drive are an RFI filter and a single-turn potentiometer.
The AF-60LP Micro Drive runs at 1 horsepower, and has an output power of .75 kilowatts. The output rating of the device is 2.2 amps. The general efficiency rating of the micro drive 96% with a wattage loss of 43.5.
The AF-60LP Micro Drive uses three separate input phases to work together and complete the operations of the drive. The input voltage of the device is 460V, 50/60 Hz.
