40HP Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 6KP1143040X9B1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 6KP1143040X9B1
  • SKU: 6KP1143040X9B1GD
  • Manufacturer: GE Drives
  • Series: Fuji Electric

Product Description

The 6KP1143040X9B1 by Fuji Electric. This drive is a 460 VAC, 3 phase, 50/60Hz input, and is open. This drive has forty horsepower with a 66 overload (110% 1min), and a sixty rated output current (A). The drive weighs sixty-four pounds. The dimensions of this drive are 21.7 (H) x 13.4 (W) x 10.0 (D) inches. The drive has a rated output power (KVA) is forty-seven. The Ambient Temperature -10° to +50°C (+14° to +122°F) – for products of 30 HP or less, the ventilating covers must be removed if the ambient temperature exceeds +40°C (104°F). The atmosphere is this product must not be exposed to dust, direct sunlight, corrosive gas, oil mist, vapor, or water. There must be a minimum salt content in the atmosphere. Do not store where condensation may occur as a result of sudden changes in temperature. The altitude recommended at 1000 m (3300 feet) or lower. A drive of 40HP or more can be converted to external cooling simply by moving the upper and lower mounting brackets as shown in Fig. 2-2-3. Remove the M6 bracket screws, move the brackets, then secure the brackets using the M5 case mounting screws. (The bracket screws are no longer required after changing the bracket mounting position.) Fuji Electric has produced a detailed instruction manual titled AF-300 P11. This manual has in-depth details about the product and easy to read follow charts and diagrams.

If you would like more information about this product AX Control’s staff is here to help.

Repair Services For 6KP1143040X9B1

Type Lead Time Price Action
Repair Service 1-2 weeks $878

Our highly skilled technicians can repair your 6KP1143040X9B1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

6KP1143040X9B1 Manuals, White Papers, Data Sheets, and Troubleshooting
