IC210BDD012

About the IC210BDD012

IC210BDD012 is a product of GE and belongs to the Durus PLUS 20 series of controllers. It has a built-in display and keypad, a maximum ampere rate, and different communication paths with low error rates. This controller also contains programming software, which makes its use in logic applications and RTC handling very simple. This Durus product is created for simple control applications, such as light control, gate control, HVAC, and pump control. It is compatible with seven languages and contains 15 possible text displays.

This DC version 20-point controller has 12 discrete inputs, wherein analog inputs can be configured as either discrete inputs or analog inputs. This unit also supports high speed inputs and PWM output. The controller is compatible with expansion to a maximum 36 input/output ports.

The chassis can be mounted either vertically (on a vertical surface) or horizontally on the DIN rail. The module includes power supply terminals, an LCD display, input terminals, retractable mounting feet, a delete key, a select key, arrow keys, an OK key, an escape key, a communications port, and output terminals. Please refer to the manual for more information about mounting and configuring your controller.

IC210BDD012 has input power voltage of 24 VDC with 90 mAmps power supply power consumption. It has 24 VDC control output voltage. The dimensions for IC210BDD012 are 72 mm x 90 mm x 58 mm. The supported protocols for IC210BDD012 are Modbus Slave, DeviceNet Slave and ProfiBus expansion modules. The user program logic memory has 200 Rungs and 99 Blocks.
