IC210EPT004

About the IC210EPT004

The IC210EPT004 unit is an Analog Expansion Unit made to be part of the Durus series of controllers and controller accessories. More specifically, the IC210EPT004 module is a temperature input module (RTD).

The Durus Controllers have many key features that make it easily accessible and able to handle a wide variety of applications. The Durus Controllers have a Programmable Relay, Analog Inputs, Relay or DC Outputs, and AC or DC Inputs. Durus Controllers models can have up to 44 I/O ports and are available in either 10-Point, 12-Point, 20-Point, 24-Point models. All of the Durus Controllers have a built-in real time clock, simulator mode via the software, retentive Flash memory, a 12 character LCD backlit display, an optional built-in keypad or display, and 17 custom user screens. The Durus Controllers all also have multi-language support: English, Spanish, Italian, French, German, Portugese, and Chinese.

The Durus Controllers were created to be able to support up to 7 I/O expansion modules and 1 communications module. The total expansion supports up to 3 discrete modules, up to 2 analog output expansion units, 1 analog input module, 1 temperature input module (RTD).

The IC210EPT004 module, in particular, is the aforementioned temperature input module (RTD). Thus, this is the maximum amount of temperature modules supported on a Durus Controller. The IC210EPT004 module has a mature lifecycle status and 4 channels. The IC210EPT004 unit’s resolution is set to be 0.1C. Lastly, the IC210EPT004 module’s dimensions (W x H x D) in millimeters is as follows: 38 mm x 90 mm x 58 mm.
