IC300DIQ624

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
8 Point I/O CSQ

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IC300DIQ624 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IC300DIQ624
  • SKU: IC300DIQ624GFP
  • Manufacturer: GE Fanuc PLC
  • Series: IC300 OCS

IC300DIQ624 Technical Specifications

Manufacturer GE Fanuc
Series Smart Stack
MPN IC300DIQ624
Type Mixed Module

Product Description

The IC300DIQ624 unit is an AC I/O module that was made for the SmartStack series by GE Fanuc. This product can normally be found in AX Control’s stock. To verify its current state in our stock, feel free to contact us over the phone or through email.

The IC300DIQ624 AC I/O module has a total of eight inputs, which have only one common. This device has eight LEDs on its faceplate, which is used to show the user the status of the IC300DIQ624 AC I/O module’s eight inputs. The input voltage range is 120 through 160 VAC, with the latter voltage rating being the peak voltage. The ON voltage level has a minimum of 70 VAC, while the OFF voltage level has a maximum of 30 VAC. The AC frequency rating is 60 Hz and the channel to bus isolation is rated 500 VDC.

The IC300DIQ624 AC I/O module has a total of eight outputs, which have only one common. This device has the MOSFET output type. Both the operating voltage and the contact voltage have a maximum rating of 260 VAC. Similar to the IC300DIQ624 AC I/O module’s inputs, the channel to bus isolation is 500 VDC. The maximum inrush current is 500 mA, the maximum load current is .3 A, and the maximum leakage current is 15 µA. This module has eight more LEDs, which are used to indicate the status of this device’s outputs.

As a whole, the IC300DIQ624 AC I/O module requires 0.18 W of power at steady state. In addition to that, the module has removable spring clamp terminals. This device also weighs 0.59 lbs. or 0.27 kg.

Frequently Asked Questions about IC300DIQ624

What is the function of the IC300DIQ624?
The IC300DIQ624 is a mixed module that contains in the Smart Stack Series. The IC300DIQ624 features 8 AC inputs and 8 AC outputs.
How many of the IC300DIQ624 can you place in a TIU20X?
You can install up to four IC300DIQ624's in a TIU20X.
Will AX Control purchase my IC300DIQ624?
AX Control will purchase a majority of your decommissioned surplus as well as your stock shelf surplus. Our AX Control team will review your IC300DIQ624 and then proceed with an offer.

Repair Services For IC300DIQ624

Type Lead Time Price Action
Repair Service 1-2 weeks $223

Our highly skilled technicians can repair your IC300DIQ624. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

IC300DIQ624 Manuals, White Papers, Data Sheets, and Troubleshooting
