QPI-PBS-202

About the QPI-PBS-202

QPI-PBS-202

This QuickPanel Communication module is the QPI-PBS-202, and is the connection between the Profibus Interface module. While there is also the other module attachment, the QPI-PBS-201, this module is capable of maintaining its memory retention, and includes a CE Mark. This communication module is designed as the Profibus interface for any and every of the QPI and QPL touch screen models.

The QuickPanel touch screens are a part of their regularly sized models, as opposed to their QuickPanel Junior models. The two size specifications for the QPI and QPL units are 10.5 diagonal inches and 12.1 diagonal inches, respectively.

The 10.5 inch QuickPanel units are outfitted with the dimensions of 9.57 inches/243 millimeters in height, 12.48 inches/317 millimeters in width, and then has a depth of 2.28 inches/58 millimeters. The weight of these models are 7.7 pounds, or 3.5 kilograms. These models have three options for lighting and displays, with an LCD (liquid crystal display) setup, an STN (super twisted nematic) display, and an amber electroluminescent lighting system.

The 12.1 inch modules, on the other hand, are only outfitted with either an LCD or STN display, given the larger size of the models. The dimensions of the 12.1 inch units are 10.7” x 13.62” x 4.45”, or 272 mm x 346 mm x 113 mm. The weight is 8.4 pounds, or 3.81 kilograms.

The QPI-PBS-202 communication module, as well as all of the other QuickPanel inventory, has been fully refurbished by our technicians at AX Control.
