IC609SJR124

About the IC609SJR124

Part of the Series One Junior line of products, the IC609SJR124 module was designed by GE Fanuc to be one of many different types of their programmable logic controllers that they developed for that series. This product has since had its production halted; despite that, we here at AX Control still regularly have it in stock for the convenience of our valued customers.

The IC609SJR124 PLC has two sets of terminals, which are located on the top and bottom parts of the device, that are both have a voltage rating that is set to 24 VDC. The top terminals are responsible for the source input, while the bottom terminals are responsible for the relay output. The IC609SJR124 PLC requires 24 VDC of power in order to start up and begin operations.

In addition to the two sets of terminals, the IC609SJR124 PLC also has a display screen in the bottom right hand corner, which has a set of numerous corresponding indicator LEDs next to it. To the display screen’s left, you will find a long, thin port with male connectors. Above that port, there are four LEDs that are designed to indicate the status which is labeled to the left of them.

The internal fuses of the IC609SJR124 PLC are miniature type and normal blow type. There is one miniature fuse, whose current is rated at two Amps, and two normal blow fuses, whose current is rated at five Amps.

The IC609SJR124 PLC weighs, without adding in any shipping materials whatsoever, about 1.90 lbs. or 0.86 kg.
