IC800VMTBC005

About the IC800VMTBC005

IC800VMTBC005 is a VersaMotion Breakout Terminal Board that is manufactured by GE Fanuc Automation. This board comes with a 0.5 meter cable.

The breakout terminal board is part of the VersaMotion servo system alongside a CN3 serial communications cable, an encoder cable (used to connect the encoder of the servo motor and the CN2 terminal of servo drive), a power cable (used to connect the servo motor and the servo drive’s U, V, and W terminals), an operating level (used for wire to terminal block insertion), a servo motor, a servo amplifier, a five-pin terminal block (used for L1, L2, R, S, and T), and 2 three-pin terminal blocks (used for U, V, and W as well as P, D, and C). The terminal blocks are included with the amplifier.

The terminal breakout board and cable are accessories to the VersaMotion controllers. When the I/O breakout terminal board or flying lead I/O interface cable are not used for wiring access to the amplifier I/O points, the CNI connector is required. The VersaMotion Interface can be used for applications such as high-speed printing, packaging systems, high-speed assembly, woodworking machinery, automotive assembly, material handling, web handling applications, infeed conveyors, labeling, and filling. The terminal board allows for easy access to any additional I/O connections to the VersaMotion amplifier from field devices such as emergency stop circuits. Refer to the user manual for diagrams and further specifications. Pay attention to caution warnings when installing and operating the VersaMotion system.
