The 345-EP1G1HESNN1ENN is a high-voltage model in the 345 series of transformer protection systems from GE Multilin.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 345-E-P1-G1-H-E-S-N-N-1E-N-N to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 345-E-P1-G1-H-E-S-N-N-1E-N-N
  • SKU: 345EP1G1HESNN1ENNGM
  • Manufacturer: GE Multilin
  • Series: 345 Transformer Protection System

345-E-P1-G1-H-E-S-N-N-1E-N-N Technical Specifications

Manufacturer GE Multilin
Series 345 Transformer Protection System
Part Number 345-E-P1-G1-H-E-S-N-N-1E-N-N
Case Design Non-drawout
Current Protection Standard
Ground Current Input 1A
3-Phase Current Inputs 1A
Harsh Environment Conformal Coating No

About the 345-E-P1-G1-H-E-S-N-N-1E-N-N

General Information

The 345-EP1G1HESNN1ENN is a transformer protection relay in GE Multilin's 345 series. This unit can provide protection, control, and management to small or medium sized power transformers. Programmable logic allows this unit to serve a wide range of applications. Models in this series were created from a list of optional components. This model is relatively standard when compared to the baseline of this series.

Relay Functionality

One of the main strong points of the 345-EP1G1HESNN1ENN is its communications package. This package includes support for Ethernet as well as IEC 60870-5-104, DNP3.0, and Modbus TCP/IP protocols. This unit has the less-common 1A ground and three-phase inputs as well as a high-voltage 110-250VDC/110-230VAC power supply. This model has all the standard current protections from this series, which include percent differential among other key protections.

Environmental Ratings

The 345-EP1G1HESNN1ENN has a non-drawout case design and does not have harsh environment conformal coating. This unit is rated for an operating temperature range of -40 to 60°C and a storage temperature range of -40 to 85°C. This unit is rated for humidity levels up to 95% non-condensing at a temperature of 55°C. This model is rated for pollution degree II environments and a maximum altitude of 2000 meters.

Frequently Asked Questions about 345-E-P1-G1-H-E-S-N-N-1E-N-N

What is the weight of the 345-EP1G1HESNN1ENN?
The 345-EP1G1HESNN1ENN weighs 8.6lbs/4kgs gross and 6.4lbs/2.9kgs net.
What are the dimensions of the 345-EP1G1HESNN1ENN?
The 345-EP1G1HESNN1ENN measures 7.98 inches high x 6.23 inches wide x 9.35 inches deep.

Reviews For 345-E-P1-G1-H-E-S-N-N-1E-N-N

Internal Review
(4.0)

The 345-EP1G1HESNN1ENN is lacking in a few quality-of-life features that would stand to improve the user experience with this relay. Despite this, the relay is still well suited to handle transformer systems. The Ethernet functionality significantly widens the range of existing systems this relay can fit in to. -AX Control Lead Technician

  • 345-EP1G1HESNN1ENN

Repair Services For 345-E-P1-G1-H-E-S-N-N-1E-N-N

Type Lead Time Price Action
Repair Service 1-2 weeks $1193

Our highly skilled technicians can repair your 345-E-P1-G1-H-E-S-N-N-1E-N-N. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
