369-HI-R-B-0-E-0-E

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The 369-HI-R-B-0-E-0-E is one of the models that comes with the optional embedded Ethernet port, allowing users to connect the relay to the network and subsequently access it remotely from their desktop running the EnerVista 369 software. Ethernet is an especially cost-effective option for companies running dial-up or leased connections, offering a self-sustaining alternative to these two options.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 369-HI-R-B-0-E-0-E to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 369-HI-R-B-0-E-0-E
  • SKU: 369HIRB0E0EGM
  • Manufacturer: GE Multilin
  • Series: 369 Motor Management Relay

369-HI-R-B-0-E-0-E Technical Specifications

# of Digital/Switch Inputs 6 optically isolated
# of Recordable Events 512
Fuse 3.15 A H 250 V
Ground Current Input Frequency 20 to 100 Hz
Manufacturer GE Multilin
Maximum Altitude 2000 m (max)
Pollution Degree II
Software EnerVista 369

About the 369-HI-R-B-0-E-0-E

General Electric Multilin’s 369-HI-R-B-0-E-0-E takes the guesswork out of motor system management by monitoring, protecting, and controlling the system using industry-leading adaptive technology alongside the EnerVista 369 software program. A part of Multilin’s 369 series, the 369-HI-R-B-0-E-0-E is able to ‘learn’ a motor system’s unique requirements and adjust accordingly in order to ensure best functionality.

General Electric’s industry-leading EnerVista 369 software program makes setpoint configuration and system monitoring easier than ever. Installing the program on a computer and connecting it to the relay via the RS232 port located on the front of the panel enables users to access a more expansive UI than is offered by the 40-character LCD. Data points such as temperature and frequency can be trended and exported for further review. EnerVista 369 has an additional testing feature that allows the relay to simulate normal functions without requiring a test set.

The 369-HI-R-B-0-E-0-E is one of the models that comes with the optional embedded Ethernet port, allowing users to connect the relay to the network and subsequently access it remotely from their desktop running the EnerVista 369 software. Ethernet is an especially cost-effective option for companies running dial-up or leased connections, offering a self-sustaining alternative to these two options. It also replaces a multi-drop wired network, reducing the need for auxiliary equipment to be installed in the system.

Frequently Asked Questions about 369-HI-R-B-0-E-0-E

What features are additional to the base motor management relay for the General Electric 369 Multilin motor management relay 369-HI-R-B-0-E-0-E? How are these options unique to the 369-HI-R-B-0-E-0-E compared to the base 369 Multilin motor management relay General Electric digital relays?
The General Electric 369 Multilin motor management relay 369-HI-R-B-0-E-0-E includes a HI (high) control power feature. This voltage alternating current has a range from 60 to 265 VAC. The VDC ranges from 50 to 300. This 369 Multilin digital motor management relay 369-HI-R-B-0-E-0-E also has the optional RTD input built-in option. This (R) option allows the 369 Multilin GE relay to monitor up to twelve RTDs. These RTDs can either be from bearings, ambient, stator, or driven equipment sources.  The 369-HI-R-B-0-E-0-E also includes the (B) or the backspin detection feature which allows the relay to pick up on the situation where the pump motor's flow has reversed. The 369-HI-R-B-0-E-0-E also has the feature of an enhanced faceplate and enhanced diagnostics. This enhanced feature also affords the 369-HI-R-B-0-E-0-E an additional learned data capabilities, a motor start data logger and an enhanced event recorder with security trail events (audits). The 369-HI-R-B-0-E-0-E can generate a motor health report summary with this enhanced option (E). The 369-HI-R-B-0-E-0-E contains the optional Modbus/TCP protocol interface feature as well.

Reviews For 369-HI-R-B-0-E-0-E

Internal Review
(5.0)

This version of the 369 comes with enhanced diagnostic capabilities, denoted by the “E” in the product description. This makes it perfect for users requiring an enhanced event record or enhanced audit trail. -AX Control Tech Team

Repair Services For 369-HI-R-B-0-E-0-E

Type Lead Time Price Action
Repair Service 1-2 weeks $1909

Our highly skilled technicians can repair your 369-HI-R-B-0-E-0-E. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
