Able to function as a standalone unit or alongside other relays in the General Electric Multilin 745 series, the 745-W3-P5-G5-HI-E Transformer Management Relay is invaluable for directing and protecting transformers of any size. It can also record and trend collected data within the EnerVista 745 software program.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 745-W3-P5-G5-HI-E to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 745-W3-P5-G5-HI-E
  • SKU: 745W3P5G5HIEGM
  • Manufacturer: GE Multilin
  • Series: 745 Transformer Protection System

745-W3-P5-G5-HI-E Technical Specifications

Weight 4.8kg
Voltage Input Burden less than 0.025 VA at 120 V
Source VT 2 to 600 kV / 60 to 120 V
# of Logic Inputs 16
Manufacturer General Electric Multilin
Fuse Current Rating 3.15 A
Features Enhanced Display, High Control Power

About the 745-W3-P5-G5-HI-E

Able to function as a standalone unit or alongside other relays in the General Electric Multilin 745 series, the 745-W3-P5-G5-HI-E Transformer Management Relay is invaluable for directing and protecting transformers of any size. Manufactured with a wide range of adaptive capabilities, the 745 can adjust to a transformer system’s unique variables and requirements.

The 745 does not only respond to these variables; it can also record and trend this data within the EnerVista 745 software program. Computers with EnerVista 745 installed can utilize the RS232 port or RS422/485 port to successfully connect to the relay. From there, setpoints can also be assigned, edited, deleted, or added as users see fit.

This version of the model comes with an enhanced display, which boasts a wider screen, expanded keypad, and twenty LEDs that provide quick reference for system health. Some of these LEDs include self-test error, differential blocked, transformer de-energized, and transformer overload. The LEDs can be green, amber, or red depending on the condition of these processes, with amber and red functioning as different levels of severity.

The GE Multilin 745 includes both time/overcurrent elements and instantaneous differential elements. While some users question if both of these elements are necessary, the combination of both features provides more sensitive protection. This is because the instantaneous differential element can be set to a lower value than overcurrent elements, limiting damage and time consumption. Differential protection is also selective (operating within a specified zone, clearing faults more quickly) while O/C protection is not selective and therefore more delayed.

Frequently Asked Questions about 745-W3-P5-G5-HI-E

The 745-W3-P5-G5-Hi-E Multilin has which type of control power?
The General Electric 745-W3-P5-G5-Hi-E Multilin Transformer Protection System is three winding with voltage control powers of the high classification. In other words, for direct current, the voltage ranges from 90 to 300 volts, and for AC the range is from 70 to 265 volts in the realm of 48 to 62 Hz. This is in contrast to the low control power option, which ranges from 20 to 60 volts of direct current and from 20 to 48 AC in the same range of Hz.
What options are included in the 745-W3-P5-G5-Hi-E Multilin and how do you tell the difference between the different transformer management relays within the 745 Multilin series?
The 745 transformer protection systems are either two or three winding per phase. Their phase current input ratings are differentiated by the numeric code following the P letter in the part number (ex. P5). Similarly the ground current input rating is differentiated by the number following the G letter (ex. G5). In this case, the 745-W3-P5-G5-Hi-E Multilin is a high control power transformer protection system. The option that follows this control power designation is specified by the letter E. The E option includes an enhanced display with a larger LCD.
