750-P5-G5-D5-HI-A20-R

About the 750-P5-G5-D5-HI-A20-R

A high control power range model of the series, 750-P5-G5-D5-HI-A20-R is a Distribution Feeder Management Relay produced by General Electric Multilin. Equipped with a variety of protective measures, the relay can be used as a standalone unit or mounted alongside other SR-series units.

This unit has eight analog outputs, two of which are factory programmed for breaker control, one is factory programmed as an alarm relay, and the other five are user-configurable to be controlled by any feature. This version of the model’s analog outputs are all 4 to 20 mA, denoted by the “A20” in the model number.

If retrofitting is necessary, the Multilin SR 750 series comes with the Retrofit Kit, which offers users a 3-step process to upgrading existing 750 relays. The Retrofit Kit reduces upgrade costs as it simplifies a previously lengthy and intensive task. Users need only update their settings file, replace the relay itself, and then reconnect using Multilin’s Plug & Play technology.

For users needing to remotely access the relay more efficiently, the 750 relay has an optional ethernet port that allows the relay to be connected to an existing network. This is especially cost-effective for users who are actively paying for multi-drop connection or the more archaic dial-up services. While this version of the part does not contain the option ethernet port, models with this feature are listed on the AX Control website: please inquire within.
