UR-9JH Image One
3 year warranty

❯

UR-9JH Image 1
UR-9JH Image 2
UR-9JH Image 3
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

UR-9JH

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
A module designed for the Universal Relays series, GE Multilin's UR-9JH is a CPU module that provides the relay with highly configurable logic frameworks.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a UR-9JH to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: UR-9JH
  • SKU: UR9JHGM
  • Manufacturer: GE Multilin
  • Series: UR Series Universal Relays

UR-9JH Technical Specifications

Manufacturer General Electric Multilin (GE)
Manufacturing Location Markham, Ontario, Canada
Weight approx. 1lb, 10oz
Dimensions approx. 6.5” L, 6” W, 2.5” H
Software EnerVista UR

About the UR-9JH

A module designed for the Universal Relay’s series, GE Multilin’s UR-9JH is a CPU module that provides the relay with highly configurable logic frameworks and computing algorithms that govern the protective functions of the relay. Additionally, the module interfaces with other modules in the scalable UR unit, assisting in determining their functions and the data captured.

The Universal Relays series is designed with scalability in mind, so replacing old modules and installing new ones is a relative breeze, especially when combined with following the verbal and pictorial guides offered by the Universal Relay’s manuals.

Purchasers of any of Multilin’s CPU modules should carefully read and understand their respective user manual before installing the CPU module, as there are a number of guidelines to ensure proper function and protect the user. For example, users must properly disconnect each individual connection from the current CPU module before removing the relay from the chassis, or else user harm/system damage could occur.

Frequently Asked Questions about UR-9JH

If the CPU UR-9JH Multilin UR series has two Ethernet ports, which one takes priority if both are connected?
The UR-9JH is unique because in January of 2015 a hardware revision was finalized based on the popularity of an Ethernet copper port originally found on the '9G' and 9H' CPU modules for UR series universal relay systems, that are now obsolete. This hardware revision enhanced the communication features of the '9K' and the '9J' CPU modules by adding this copper Ethernet port to the lower right side (rear view). Thus for the new revision, there may be a situation where the original fiber Ethernet port (100Base-FX) and the new copper (10/100-TX) Ethernet port are both connected at the same time. In this event, the original 100Base-FX fiber Ethernet port will assume the Ethernet connection.
Can the UR CPU module be ordered as a spare unit separate from the Multilin UR series original relay?
The answer to your question is certainly. The existing 18 UR products of the UR Multilin series may already contain a CPU module, a power supply, etc. The user may also purchase a UR replacement kit or a separate UR CPU module in the event of desiring a spare for replacement. This may be an example of a situation where the original UR-9JH Multilin CPU does not have the copper 10/100Base-TX Ethernet port, but the replacement ordered does.

Reviews For UR-9JH

Internal Review
(4.0)

The UR-9JH must be paired with a suitable CT/VT module, as CT/VT modules and CPU modules must be produced around a similar time, or else an error will be detected and displayed by the relay. -AX Control Technician

Repair Services For UR-9JH

Type Lead Time Price Action
Repair Service 1-2 weeks $1636

Our highly skilled technicians can repair your UR-9JH. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
