UR-RHV

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
General Electric Multilin's UR-RHV is a UR Series second generation Power Supply Module.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a UR-RHV to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: UR-RHV
  • SKU: URRHVGM
  • Manufacturer: GE Multilin
  • Series: UR Series Universal Relays

UR-RHV Technical Specifications

Manufacturer General Electric Multilin
Manufacturing Location Markham, Ontario, Canada
Weight approx. 2lb, 2oz
Dimensions approx. 6.5” L, 6.5” W, 1.75” H

About the UR-RHV

The “V” in the order code for the UR-RHV indicates that this module is intended for the vertical mount version of the Universal Relay series. The vertical mount units are reduced in size and intended for users with limited available space in their power system. Prospective buyers should ensure they are purchasing the module appropriate for their unit (horizontal or vertical) as there is a distinct difference between the two versions of the modules.

The Universal Relays series power supply modules have a redundant option which includes two power supplies placed in parallel with one another; if there is a fault in one of the power supplies, the other can take on the full load of the power system. This switchover happens instantly and results in zero downtime for the power system. The LEDs located on the front of the faceplate will also indicate when this failure occurs so that users can get the one power supply up and running while the other continues to take on the labor.

While some of the modules are not inherently necessary for relay function, the power supply module (along with the CPU module) is required for operation, as the relay cannot run without a connected source.

Frequently Asked Questions about UR-RHV

What is the function of the UR-RHV power supply module?
The UR-RHV is a Multilin General Electric power supply module and is compatible with the Multilin series of universal relays. For example, the Multilin universal relays include the D30 line distance relay, C30 I/O logic controller, and the T60 transformer management relay. The universal relays have slots to accept a Multilin power supply to receive power to the universal relay similar to the UR-RHV power supply module for example. Over the years, GE Multilin has come out with three types of power supply modules, the UR-1H series, the UR-RH generation, and most recently the UR-SH. The UR system of universal relays is compatible with the updated power supply modules as well even if it was first purchased with a power supply of the original generation. Similarly some universal Multilin relays require two power supply modules. In this event, the recommendation is that the generations remain the same for the two power supply modules included with the universal relay.
What is the power rating for the UR-RHV power supply module for Multilin universal GE relays of the UR Multilin series?
The power rating for the UR-RHV Multilin power RH generation is 125 to 250 V at 35W and 100 to 240 VAC at 35 VA.

Reviews For UR-RHV

Internal Review
(4.0)

The UR-RHV contains the unit’s battery, which is occasionally prone to failure and may need to be replaced. Fortunately, detailed instructions can be found in the Universal Relays user manuals that guide the users on how best to carry out this process. -AX Control Tech Team
