HE693OIU360A-485

About the HE693OIU360A-485

Originally designed and manufactured by Horner, the HE693OIU360A-485 board is classified by Horner as a Digital Interface Board with Display. AX Control has the HE693OIU360A-485 board in stock today! We have the HE693OIU360A-485 board available for purchase in reconditioned form and we may also have the HE693OIU360A-485 board in new, never touched condition.

The HE693OIU360A-485 board is equipped with two serial ports an RS-485 and RS-232. Additionally, the HE693OIU360A-485 has 5/24 VDC capabilities.

At the top of the display, there is a large green display. The display is an LCD screen with capabilities of displaying two lines and twenty characters. Below the display, there are thirty-two buttons meant for user input. On the left hand side of the HE693OIU360A-485 board, there are twelve orange buttons with various inputs in black text. For example, some of the buttons read in black text, “PRIORITY CONVEY” and “SYSTEM STATUS.” On the right hand side, there are twenty buttons of various colors. There are seven gray buttons of various inputs. The gray buttons read in black text, “Yes,” “No,” “Help,” “Special,” “Escape,” “Clear,” and “Shift.” On the very right side of the board, there are three buttons: one green, one red, and one light blue. The green button has black text which reads, “Start,” the red button has black text which reads “Stop,” and the light blue button has black text which reads, “Alarm Silence.” In the middle of the right side of the keypad, there are ten yellow buttons with black text which individually have numbers 0 through 9 printed onto them.
