PFXGE4408WAD

About the PFXGE4408WAD

The PFXGE4408WAD Touchscreen Display was manufactured as part of the Pro-face GC4000 Series and was made with a 7" Touchscreen that allows the user on the facility floor to operate the production line directly from the HMI. It conforms to USB Type-A and Mini B and uses asynchronous transmission. This model uses functional grounding methods, and should only ever be cooled through natural air circulation. It uses flash for both application and backup memory. Clock accuracy for the display can vary based on battery life or operation conditions. This variation can be from -380 to +90 seconds a month. Surrounding air temperature for model PFXGE4408WAD should be kept between 32 and 122 degrees Fahrenheit. It should stay free of corrosive gases and can be used in pollution degree 2 environments.

This display monitor is equipped with simplified Chinese language fonts and uses standard character font sizes. Other display features of model PFXGE4408WAD include;

• Display size of 7 inches wide.
• 65,536 display colors.
• LED backlight with 20,000 hours or more of service life.
• 8 levels of brightness control.
• Resistive film touch panel with a lifetime of one million or more.
• Display resolution of 800 x 400 pixels.
• TFT Color LCD display type.

This monitor has been discontinued by Pro-face, but can be found in other places, such as AX Control. AX Control can buy and sell these products, as well as offer repairs on them.
