GLC100-SC41-24V

About the GLC100-SC41-24V

GLC100-SC41-24V is from Pro-Face. This operator interface has a power supply rating of DC 20.4V to DC 27.6V. It consumes 20W or less of power. It can withstand AC 1000V- 10mA for one (1) minute between the live wire and the grounding terminals. The isolation resistance is DC 500V- above 20M Ohms between the live wire and the grounding terminals. This panel has a vibration resistance of 10 to 25 Hz (X, Y, Z directions- 30 minutes each, 19.6 m/ s2). The noise immunity of the GLC100-SC41-24V is 1000Vp-p with a pulse length of one microsecond and an arise time (rise/fall) of one nanosecond. The GLC100-SC41-24V can ground out at 100 Ohms or less. The panel has no protection against freezing temperatures. The GLC100-SC41-24V has an STN-type color LCD. It offers eight (8) colors (white, red, blue, green, yellow, magenta, cyan, and black). The intermediate colors are displayed via tiling. The panel has a CCFL backlight which offers 20,000 hours at continuous operation and can be replaced by the user if needed. The panel has eight contrast levels and two brightness levels. The number of characters on the screen varies at 8x8 dots it shows 40 characters in 30 rows, 8x16 dots shows 40 characters in 15 rows. For Kanji characters 16x16 dots it shows 20 characters in 15 rows. The fonts can be enlarged in multiples of 1, 2, 4, and 8. High-quality fonts are used for the characters that are larger than 32 x 32 dots.
