GP2501-LG41-24V

About the GP2501-LG41-24V

General

The GP2501-LG41-24V is a 10.4-inch human-machine interface (HMI) from Xycom/Proface. It is a basic model in certain features compared to the 00 models in this series. Notably, this model has a reduced memory capacity and no ethernet network interface. This serves to make this a more affordable HMI for those who do not require features such as these for their situation. In addition to standard HMI functionality, this touchscreen operator panel offers serial connectivity along with industrial networking capabilities.

Functional Specifications

The GP2501-LG41-24V has a monochrome black/white LCD screen surrounded by a large bezel. The effective display area of this model is 8.34 in (211.2 mm) by 6.24 in (158.4 mm), with a resolution of 640 by 480 pixels. The rear of the GP2501-LG41-24V includes an RS232/422 com port, a power supply terminal block, a CF card interface, and an 8-pin mini-DIN designed for a bar code reader or to allow for programming. This unit has 2 MB of Flash memory along with 128 KB of backup SRAM.

Operational Conditions

The GP2501-LG41-24V should only be used in locations where the non-condensing humidity remains below 90%. This unit is not rated to operate above ambient temperatures of below 0 degrees Celsius or 50 degrees Celsius. Because it relies on air cooling, installation must follow OEM guidelines. Air purity must be at non-conductive levels for this unit to operate normally. The GP2501-LG41-24V accepts a 24 VDC power input and has a power consumption of 50 W or less. The total allowable voltage range for this unit is from 19.2V to 28.8V of DC power.

Dimensions of the GP2501-LG41-24V are included below.
