GP470-EG21-24VP

About the GP470-EG21-24VP

The GP470-EG21-24VP is an Amber monochrome HMI (human-machine interface) from Proface Xycom.  This unit is CE marked and conforms with EMC Directive EN55022 Class A as well as EN50082-2.   AX Control maintains an onhand stock of many ProFace graphics panels.  If this isn’t the exact unit you’re looking for, please take a look at our other inventory for additional options.

The GP470-EG21-24VP fastens to the panel using Proface HMI mounting clips.  These installation fasteners are specifically designed to attach the unit into the panel properly.  As a standard GP unit, it can attach to a PLC, a personal computer or a printer.  It also has options for a bar code reader or a memory loader.

The GP470-EG21-24VP has an input voltage of 24 VDC +/- 20%.  Be sure to use the correct power supply for your graphics panel unit.  The wrong power source can result in damage to both the HMI and the power unit itself.

Make sure when you connect wires to the GP470-EG21-24VP’s supply terminals to use crimp-on ring terminals.   Make sure the connections are connected correctly before reattaching screws.  Don’t use too much force to tighten back the terminal screw, as this may damage the unit.

AX Control works hard to fulfill your orders for Proface Xycom HMIs quickly and efficiently.  If you are close by our Raleigh facility, we’re happy to work with your courier service and to have them pick up your order locally at our warehouse.   Expedited shipping options are available for other customers who may need parts more quickly.
