GP577R-SC41-24VP

About the GP577R-SC41-24VP

General Information

The GP577R-SC41-24VP is a member of the GP-477R/577R series of HMIs from Pro-face/Xycom. The GP installation gasket accompanying this model helps protect the unit by creating a moisture-resistant seal. This unit accepts 24 VDC power input and supports multiple language fonts. The supported fonts include ASCII, Korean, Japanese, Taiwanese, and Chinese.

Display Specifications

The GP577R-SC41-24VP model's screen measures at 10.4 inches diagonally and is designed with a liquid crystal display (LCD) set up, complete with a CCFL backlight unit. The graphic display is rendered in a full-color display and has an image resolution of 640 by 480 pixels.The backlight allows for the brightly lit screen to be viewed easily, regardless of the intensity of external lighting. This brightness level is adjustable up to 4 distinct levels, with the contrast being adjustable to 8 levels. The display area measures at 211.2 mm (8.31 in) wide by 158.4 mm (6.24 in) high. The screen memory of this model consists of 2MB of internal flash EPROM and 96 KB of backup SRAM using the lithium battery.

Physical Characteristics

This unit has external dimensions of 317 mm in width (12.5 inches), 243 mm in height (9.6 inches), and 85 mm in depth (3.5 inches). It weighs just under 3.5 kilograms (7.7 pounds). The advised ambient operating temperatures for this model are between 0 and 40 degrees Celsius. The recommended humidity levels are between 30 and 85% RH (non-condensing). This unit has an environmental protection rating equivalent to IP65f, making it able to resist intrusion from dust, water, and oils from most industrial environments.
