AGP3500-T1-D24

About the AGP3500-T1-D24

Display Features

The Pro-face AGP3500-T1-D24 is an industrial human-machine interface with a 10.4" TFT color display. This LCD has a resolution of 640 by 480 and is capable of displaying up to 65,536 colors with no blink and 16,384 colors with blink. The CCFL backlight of this model is rated to have a service life of 50,000 hours assuming a constant ambient temperature of 25°C. Programming this unit can be done through the GP-Pro EX software.

Human-Machine Interface Features

The display of the AGP3500-T1-D24 features a touch panel with a resolution of 1024 by 1024. The normal service life of this touch panel is expected to be 1 million touches or more. The AGP3500-T1-D24 has 16 megabytes of flash EPROM application memory and 320 kilobytes of backup SRAM using the battery. The AGP3500-T1-D24 has 2 serial interfaces, with RS-232/422/485 compatibility and RS-422/485 compatibility respectively.

Technical Information

The unit runs on 24 volts of DC power, with an acceptable limit of between 19.2 V and 28.8 V. Natural air circulation is sufficient for cooling this unit unless the ambient air temperature around the unit exceeds 50°C. The AGP3500-T1-D24 is housed in aluminum and intended to be installed as an embedded panel. Both ambient and storage humidity levels are recommended to be between 10 and 90% RH (no condensation, 39°C maximum wet bulb temperature). The deviation of this model's internal clock is approximately 65 seconds per month assuming the unit is off and at room temperature at all times.
