AGP3600-T1-D24-FN1M

About the AGP3600-T1-D24-FN1M

AGP3600-T1-D24-FN1M is a Proface display that is part of the GP3000 series. A maximum of 4 drivers can be used with this display simultaneously. The rating for this unit is IP65. There is no video input on this interface, but there is capability for a USB I/F, an Ethernet I/F, and a CF-Card I/F. There is also PLC control functionality on the display unit. Communication port 1 is RS232/RS422/RS485, and communication port 2 is RS422/RS485. The data backup memory is 320 KB SRAM.

The GP unit connects to a twisted pair cable, which connects to a commercial hub, which connects to an ethernet network. Another connection to the GP unit is the expansion unit. The third connection to the GP unit is the function expansion memory. The fourth connection to the GP unit is either the VM unit, the DVI input unit, or the RGB input unit. The GP unit can also connect to barcode readers, conversion cables, USB cables, a USB hub, and USB memory storage. With a conversion cable, the GP unit can connect to a commercial printer. The unit may also connect to a CF card, to a mouse emulator via an RS-232C cable, or to an RS-232C isolation unit. The isolation unit may connect to a terminal block, a number of cables, a port adapter, and a host controller. Other units that can connect to this system include the COM port conversion adapter, the online adapter, and a personal computer. The personal computer can operate screen editor software (GP-Pro EX).
