PFXLM4301TADDC

About the PFXLM4301TADDC

The PFXLM4301TADDC is a Modular Type DIO LT-4301TM model from the Pro-face Schneider Electric LT4000M series. This interface panel has a 24V DC input voltage rating, and is rated at 10W or less power consumption.

The PFXLM4301TADDC is a Source Type Digital I/O only model. There are no Analog I/O points on this unit. Digital I/O Points include:

• 20 Points Standard Input, 2 of which are for Fast Input

• 10 Points Standard Output, 2 of which are for Fast Output

This panel has a 5.7” TFT color LCD display with over 65K colors and a 320 x 240 (QVGA) resolution. Screen brightness and font size can both be adjusted for clear, comfortable viewing.

This interface software is configured using GP-Pro EX. When using GP-Pro Ex, the memory specs of the PFXLM4301TADDC are:

• Application memory - Flash E.P.R.O.M. 16 MB

• Logic program area - Flash E.P.R.O.M. 132 KB (equivalent to 15,000 steps)

• Font area - Flash E.P.R.O.M. 8 MB*

• Data backup - non-volatile SRAM 128 KB (rechargeable lithium battery for data backup)

• Variable area - non-volatile SRAM 64 KB (rechargeable lithium battery for data backup)

*when this limit is exceeded, application memory is used instead.

The PFXLM4301TADDC is cooled by natural air circulation. This and many other environmental specifications must be taken into account when installing this product. Details on these specs and installation instructions may be found in the LT-4201TM/4301TM Hardware Manual.
