PFXSP5700WCD

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (3)
  • Click a star to rate this product
The PFXSP5700WCD is a premium XL 15.6" FWXGA display from the SP5000 series by Pro-face.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a PFXSP5700WCD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXSP5700WCD
  • SKU: PFXSP5700WCDPX
  • Manufacturer: Pro-face Xycom
  • Series: SP5000 Series

PFXSP5700WCD Technical Specifications

Manufacturer Pro-face
Series SP5000 Series
Model SP-5700WC
Global Code PFXSP5700WCD
Screen Size 15” wide
Resolution 1,366 x 768 pixels (FWXGA)
Display Color 16 Million Colors
Features Brightness Sensor, Auto Scaling
Input Voltage 12 -24 VDC
Touch Screen Projected Capacitive (5 points multi-touch)
Enclosure Ratings IP65F, IP67F, Type 1
Dimensions W414 x H295 x D69mm (W16.30 x H11.61 x D2.72 in.)

About the PFXSP5700WCD

Module Overview

The PFXSP5700WCD is a display module in Pro-face's modular Smart Portal SP5000 series. This is a 15.6" extra large, high-resolution widescreen display with features such as a glass top design, durable aluminum bezel, front USB, and touch cancellation. This is the smaller of the two premium widescreen displays in this series.

Display Features

The PFXSP5700WCD has a 5 point, multi-touch projected capacitive touch screen with a 2048 by 2048 resolution. This top end touch panel is rated to have a service life of 50,000,000 touches or more. The white LED backlight of this model is rated to last around 50,000 hours and is much more energy-efficient than older CFL and CCFL-type backlights. This unit's brightness can be adjusted between a level of 0 and 100, adding another level of convenience and flexibility that older models do not provide. The 15.6" TFT color display of the PFXSP5700WCD is capable of producing up to 16 million colors and has a FWXGA resolution of 1366 by 768 pixels.

Technical Specifications

This unit has an input voltage rating of DC 12-24V, with acceptable limits between 10.8 and 28.8V. This unit only consumes 17 W or less of power. It can operate best when the surrounding air temperature remains between 0 and 55 degrees Celsius. Storage temperatures should ideally remain between -20 and 60 degrees Celsius.

The dimensions of the PFXSP5700WCD are pictured below.

Frequently Asked Questions about PFXSP5700WCD

What type of USB is the front USB?

The front USB is Type A and Mini B.

Is the backlight user replaceable?

Unfortunately, the LED backlight is not user replaceable. It is advised to send it in for repairs.

Reviews For PFXSP5700WCD

Internal Review
(5.0)

The PFXSP5700WCD is a high-quality, premium display module. It is leagues ahead of previous generations of displays when it comes to features such as the touchscreen, TFT LCD, and the overall make of the product. The screen is very large, bright, and clear, which makes the display extremely easy to read and interact with. Features such as touch cancellation are a convenience that are not often found in past generations. The modular design of this display means that you can pair it with an equally high-quality rear box module and be able to upgrade pieces of the HMI rather than the whole HMI over the following years. -AX Control Lead Technician

  • SP-5700WC

Repair Services For PFXSP5700WCD

Type Lead Time Price Action
Repair Service 1-2 weeks $1194

Our highly skilled technicians can repair your PFXSP5700WCD. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
