About the 57C406
The 57C406 model produced by Reliance Electric must be rack-mounted and requires the ability to run a ladder logic program. This model is considered a Drive Control Mode. When being used in the AutoMax PLC series the model will typically run fault codes. One of the many AutoMax PLC racks is required, depending on what other modules are going to be used this model can be mounted in any of the PLC racks.
Along the front faceplate of the 57C406 model, there are three connectors, these connectors are labeled as P3, P4, and P5. The P3 connector has the largest amount of pin connectors. There are also two switches located near the top of the model.
During the operation of the 57C406 model, it can also provide block program capacities, the block programs associated with this model are control and BASIC capacities. Unfortunately due to a lack of information due to discontinuation documentation on the model is limited and difficult to find.
