Reliance Electric 57C414 Automax Rockwell Automate DCS 5000 Mod Bus Interface Module. This module can be used to accomplish data communication with non-reliance control equipment. This module emulates part of the Modicon 584 data table.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 57C414 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 57C414
  • SKU: 57C414RE
  • Manufacturer: Reliance Electric
  • Series: AutoMax PLC

57C414 Technical Specifications

Manufacturer Reliance Electric
Series AutoMax PLC
Part Number 57C414
Product Type Modbus Interface Module

About the 57C414

Reliance Electric designed the 57C414 to be a Modbus Interface Module. This device was very possibly also put out by Baldor Reliance or Asea Brown Boveri depending on what year it was in mass-production.

The 57C414 was originally designed to be a component in an AutoMax control system. It functioned as a Modbus Assembly Gateway Module. Its primary directive was to promote communication between AutoMax and Modbus devices and connect them. It used a specific set of Modbus directive to do this. The 57C382 has the ability can use one to four AutoMAx Processors that care on the same rack system and then used them like a Modicon 584 style device. It could then be perceived by the Modbus link. This device had the capability to support both RTU and Modbus ASCII modes.

On the faceplate of the 57C414, there are two thumbwheel dials that are labeled DROP NUMBER. One of them is also labeled 1st and the other is labeled 2nd. These switches are used to label a device's number for equipment or the network. There is an RS-232 female connection labeled GATEWAY. This port provides a way to communicate with non-AutoMax equipment.  There is a pair of LED indicators that are labeled FAULT CODE. One of them is a 7-segment LED. The other is a green OK indicator. The FAULT CODE indicator’s purpose is to alter you with error codes when it detects system defects. The 57C382 is attached directly to the backplane of an AutoMax storage rack. It can be slid into two female card slots.

Frequently Asked Questions about 57C414

What are the system power requirements for 57C414 at +5V and +12V?
At +5V, 57C414 is required to have 2.5 power. At +12V, 57C414 has 0.053 power.
What modes does 57C414 support?
57C414 supports RTU (binary) and Modbus ASCII modes.
What is the communication medium for 57C414?
57C414 has RS-232 communication.
How many drops/nodes does 57C414 support?
57C414 supports 1-99 devices.

Repair Services For 57C414

Type Lead Time Price Action
Repair Service 1-2 weeks $305

Our highly skilled technicians can repair your 57C414. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
