This 0-48673 Regulator Card was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-48673 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-48673
  • SKU: 048673RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

0-48673 Technical Specifications

Manufacturer Reliance Electric
Part Number 0-48673
Product Description Regulator Board
Part Status Now-Obsolete Legacy

About the 0-48673

The 0-48673 is a PC Regulator Card circuit board created by Reliance Electric. The regulator circuit board has a grid pattern across the surface of it. Along the short edge of the circuit board is it labeled with the alphabet (A, B, C, D etc..), and along the long edge of the circuit board, it is labeled numerically starting at zero and increasing by increments of five to one hundred and fifteen. Along the long edge of the circuit board from just after number fifty to one hundred are a series of metal tabs that are used to connect various wires using an attachment that is connected to the wire and slides onto the metal tab. Each of the metal tabs has its own alphanumeric (letters and numbers) identifier.

On the opposite long side of the circuit board is a long-raised metal row with thirty-one screws on top. Each individual section has a numerical label. This is used to connect the circuit board into the system by allowing various connections to be made, using the screws to secure the connections. Across the grid-like surface, each piece is strategically placed for the best results. The circuit board uses multiple sizes and types of capacitors to regulate and store energy for the circuit board as well as three transformers to move energy between multiple circuits.

Reviews For 0-48673

Internal Review
(5.0)

This 0-48673 printed circuit board product offering, as described previously, was originally manufactured by Reliance Electric, specifically for placement in one of their now-obsolete legacy product series. While this 0-48673 PCB has an official functional description as a Regulator Card Drive Board, it is oftentimes simply referred to as a Regulator Board, and is available for repair or replacement here today. - AX Control Lead Technician

  • O-48673

Repair Services For 0-48673

Type Lead Time Price Action
Repair Service 1-2 weeks $435

Our highly skilled technicians can repair your 0-48673. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
