Printed Master Connection Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-51377-35 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-51377-35
  • SKU: 05137735RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

Product Description

Reliance is the maker of the 0-51377-35 master connection circuit board. The circuit board has five long female pin style connectors. They are labeled from left to right TSTD, VSDA, VSAA, DC GA, CLSA. There are a numerous amount of metal pins around the circuit boards perimeter. On the left there are twelve pins labeled from top to bottom is thirty-two, thirty-one, thirty-three, one hundred and twelve, one hundred and nine, one hundred and ten, one hundred and eleven, one hundred and fourteen, twenty-eight, three hundred and twenty-six, seven, and three hundred and sixty-seven. There are twenty-seven pins on the right side labeled from top to bottom twenty-three, five hundred and sixteen, twenty-two, seventy-one, fifty-six, fifty-seven, SNUBBER, ON SIGNAL, -12VA, -6.3VA, 0VA, +6.3VA, +12VA, two hundred and forty-five, one hundred and forty-five, DISCHARGE FAIL, DISCHARGE FIRING, one hundred and twenty, one hundred and twenty-one, 38V, -12V, ninety-nine and one hundred. There are twenty-three pins across the top. The first set of four pins is labeled A A. The second set of four pins is labeled B B. The third set of four pins is labeled C C. These three sections are collectively labeled +28V with arrows pointing to two pins in each section of four. The remaining pins are labeled one hundred and sixty-three, one hundred and sixty-two, one hundred and sixty-one, THY3 (W), -12V (R), THY2 (W) -12V (R), THY1 (W), -12V (R), four hundred and fifty-one and four hundred and seventy-one.

Call or email the staff at AX Control for additional information.
