About the 0-51487-1A
The 0-51487-1A is a PC Control Board from Reliance Electric. The unit was also sold under the Asea Brown Boveri company name. This unit is typically used as part of a brake resistor in the company’s V-S Jr drives.
The 0-51487-1A weighs approximately 1.7 pounds before any sort of packing or boxing material is added. The unit is composed of a small rectangular circuit board with multiple components mounted and soldered to its surface, including a large metal carrier bolted above the upper surface of the board. Most components are numbered. The board also has a secondary part number located on its underside; this number is 75976-26a.
Board components include several screw mount connectors located along one long board edge. The unit also has several wired connectors with round screw connector loops to allow for connection to other components. The board includes diodes, resistors, capacitors, and transistors, as well as a single transformer marked TR-8825. The unit also has fuse clamps located along one edge.
More information about the proper installation or handling of this component can be accessed through original documentation from Reliance. This includes user guides, datasheets, and company manuals that will offer additional insight into the part and its proper use.
