0-52711-13 AutoMate Dual Input Board 115VAC

The 0-52711-13 is a Reliance Electric circuit board that has been discontinued by the manufacturer.  This is sometimes listed as a Baldor Reliance or Asea Brown Boveri part. The 0-52711-13 functions as an Input Module Card (115 VAC) and is designed for use in Reliance systems.

The 0-52711-13 is a five-sided card with a longer back edge as compared to its truncated front edge, and a longer right edge as compared to its left.  There is a large oval cut from the card just below the front edge, making a sort of handle. The board’s input component, which is a black casing with screw terminals and two LED indicators, is mounted to the board directly below this opening.  The input component is parallel to the top and diagonal side edge of the board.

The top surface of the 0-52711-13 is printed overall with a grid pattern.  This is marked by letters and numbers. The surface of the card is factory drilled in several locations, including one location within the body of the board that is labeled “COM” and another labeled “115V.”   Other components include capacitors that use various materials including electrolytic and ceramic, diodes, integrated circuits, metal film resistors, and carbon composite resistors. The board has surface wired points in several places.   There is a second black housing located along the back board edge; this is mounted to the board’s surface using three screws threaded from the bottom of the board.

More information regarding such things as the board’s operation, installation, or handling can be found through Reliance publications like manuals and user guides.
