0-52837

About the 0-52837

0-52837 ACCA Analog Comparator Card

The 0-52837 is a PCB fabricated and distributed by Reliance Electric.  This board is most usually used within Reliance Electric drive systems.

The  0-52837 is an Analog Comparator Card that is designed with a  faceplate connected to the circuit board component portion of the module.   This is designed with a bank of six LED indicators over a second bank of four LED indicators.  The first six LEDs are labeled FEED PERM, LOW SPD1, LOW SPD2, ZERO SPD, % OVSPD, and OVSPD. The last four LEDs are labeled STALL, TACH LOSS, FLD LOSS, and O/L.  The faceplate also has a red reset push button located near its bottom edge. These LEDs and push button are wired into the attached circuit board.

Other than the components previously mentioned, the  0-52837 is populated by multiple components, including three polyester vinyl capacitors.  One of these capacitors is secondarily supported and attached to the board using a zip tie.  The board has surface wiring. It has metal film resistors, ceramic disk capacitors, transistors, and TP test points.  The board is marked across its surface with a grid pattern. The back edge is marked with the code 802280-41A. If more detailed information regarding the operation, maintenance, or installation of this board component is desired, please refer to publications like series user guides or product manuals originally provided by Reliance Electric.  As the original equipment manufacturer, Reliance was responsible for all technical support for this product. Please read, understand, and follow all safety procedures before unboxing and beginning work with this product.
