The 0-54200-3 is a Reliance High Speed Driver

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-54200-3 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-54200-3
  • SKU: 0542003RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-54200-3

0-54200-3 High-Speed Driver

The 0-54200-3 is a circuit board component fabricated by Reliance Electric.  This board component is typically used within Reliance drive systems.

The 0-54200-3 functions as a High-Speed Driver board.  This board does not have a front faceplate; instead, it is fitted with two extractor clips along its front edge that give technicians a place to grasp the PCB during insertion into a rack, and a lever point to pull the board out of its place within the rack system when maintenance or replacement is needed.  The clips are inserted into drilled holes in the corners of the board. Other drill points are located on the other two corners of the board.

The 0-54200-3  is populated by over eighty integrated circuits, including eproms.  The board has two right-angled cable connectors. Capacitors are typically made from ceramic material.  Resistors on the board are usually carbon composite, but there are some metal film resistors used as well.  The board has several resistor network arrays. It has over a dozen transistors; the majority of these are located in a single line near the top board edge.   Surface wiring is used in multiple board locations. Most components are marked with some sort of reference designator, and some parts are marked with their manufacturer’s part number.

More information may be found through publications provided by Reliance Electric, such as data sheets or manuals. Series user guides are also helpful in providing detailed information on installation and board operation.  Reliance Electric provided all technical support for the 0-54200-3.




Frequently Asked Questions about 0-54200-3

How is voltage protection handled in the assembly of this 0-54200-3 product offering?

This 0-54200-3 device's voltage limitation is produced through its internal assembly's inclusion of sparse Reliance Electric-standardized hardware components such as capacitors, diodes, and resistors.

Can AX Control repair my 0-54200-3?

Yes. This 0-54200-3 product offering is available for both repair and replacement here at AX Control, with a standard one to two week lead repair time.
