0-54201-3

About the 0-54201-3

The 0-54201-3 is a Dual Processor PC Board from Reliance Electric.   This is one of several dual-processor boards Reliance made and that is now typically available as reconditioned stock from AX Control.  Please check your system and be sure you order the correct board for your needs.

The 0-54201-3 board is designed without a front faceplate but does include two extractor clips on its leading-edge that will help pull the board from its place within the rack system during removal.  These clips can also be used as handles during installation to protect more delicate parts of the board.

The 0-54201-3 has a printed grid system on its surface that is marked on one axis by numbers and on the other by letters.   Board components line up with this grid pattern.  These include multiple integrated circuits, along with a right-angled connector on the top edge of the board.  The unit also has several jumper switches and tp test points along with capacitors, resistors, resistor network arrays, and varistors, as well as transistors.  The board has a single LED indicator, located near the top left corner.     Some components are marked with their original manufacturer ids.

More information about the 0-54201-3 board can be accessed through your original documentation like manuals and data sheets.  This information should be re-read before you unbox your replacement part.  This is to ensure the safety of your staff as well as to increase the longevity of your new part.  AX Control may be able to help with document replacement if you no longer have these in your possession.
