This 0-54220-2 Automate Auto Bus Link Card was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-54220-2 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-54220-2
  • SKU: 0542202RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-54220-2

The 0-54220-2 is an Automate Auto Bus Link Card made by Reliance Electric. This circuit board is not shaped like other circuit boards. Along the top corner, it is angled instead of coming to a pointed corner. The right side of the circuit board is also strange in the sense that there is a oval opening cut into the circuit board. On the right side of the circuit board there is a black plastic tray that covers the angled corner and some of the circuit board. The black plastic tray has an indented surface that creates a catch cup to hold small pieces. One the right side of the black tray there are two red LED lights that stick out over the oval cut out. The circuit board has twelve black integrated circuits that are staggered across the circuit board in equal distances. The circuit board has five visible black transistors, and two visible silver circle transistors. The circuit board has five visible white resistors with striping, six visible light blue resistors with striping, and three visible light brown resistors with stripping. The circuit board has two large red boxes with tiny white righting on the top near the black plastic tray. The circuit board has two tiny blue squares with even tinier black writing on top near the bottom left of the circuit board. On the left edge of the circuit board there is a black plastic strip that is secured in three places, with thirteen silver half circles popping out of the back edge.

Reviews For 0-54220-2

Internal Review
(5.0)

A main highlightable hardware trait immediately noticeable in the assembly of this 0-54220-2 product offering has to be defined as its irregular Reliance Electric printed circuit board shape; this 0-54220-2 product offering features one corner chopped off at an angle to facilitate correct 0-54220-2 board mounting and safe installation. This 0-54220-2 PCB ships worldwide with warrantied protection. - AX Control Lead Technician

  • O-54220-2

Repair Services For 0-54220-2

Type Lead Time Price Action
Repair Service 1-2 weeks $265

Our highly skilled technicians can repair your 0-54220-2. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
