This 0-54374 Card PC Board was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-54374 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-54374
  • SKU: 054374RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-54374

The 0-54374 is an NSNP circuit board by Reliance Electric. This circuit board is relatively small. The circuit board has a sixteen-port connection terminal along the bottom of the circuit board.

Below the connection terminal etched into the circuit board it says “DANGER: circuits on this card may be main energized with main power off. Use yel. Wire and separate disconnect if req’d.” On top of the connection terminal, there is another warning label and says “DANGER: control circuit yellow wiring is energized with disconnect open”, then states the same warning in another language.

The circuit board has six large black relays. Each relay has its abilities marked into the top. The relays are also outlined in a white box on the circuit board and they are labeled 1 RLY, 2 RLY, 3 RLY, 4 RLY, 5 RLY, and 6 RLY. There are two large black resistors on the left edge of the circuit board next to relay five and relay six.

There are eight small metal pins at the top edge of the circuit board. Each metal pin is encased on a white circle on the surface of the circuit board and labeled with a set of numbers either above, below or to the side of the metal pin, depending on where it is in the lineup. The circuit board also has four holes with a metal tube placed in the hole to allow for secure installation of the circuit board.

AX Control is a leading supplier of surplus and reconditioned used industrial automation drive boards and other equipment.

Reviews For 0-54374

Internal Review
(5.0)

This 0-54374 printed circuit board from Reliance Electric does not necessarily benefit from its original placement in a now-obsolete legacy product series, as it is only functionally-definable through its very basic description as a Card PC Board, although it does make use of the NSNP functional abbreviation. This 0-54374 PCB product is available here today, however, with a guaranteed warranty upon purchase. - AX Control Lead Technician

  • O-54374

Repair Services For 0-54374

Type Lead Time Price Action
Repair Service 1-2 weeks $425

Our highly skilled technicians can repair your 0-54374. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
