0-55325-85 Bus Clamp Assembly

The 0-55325-85 is a small circuit board component used as a Bus Clamp Assembly. This board is used within Reliance drives, and most often is noted as a Reliance board.  However, the 0-55325-85 may sometimes have Asea Brown Boveri noted as the manufacturer. It may also originate from Baldor-Reliance.  55325-85 will always appear in the part number.

One of the drive systems the 0-55325-85 is typically used for includes Reliance 2000 General Purpose A-C VS Drives.  It can be used within systems rated 208 VAC, 230 VAC, 380 VAC, 415 VAC, 460 VAC and 575 VAC. These controllers are variable speed, A/C controllers that use microprocessor digital technology and offer full spectrum switch techniques.   They can be used for constant or variable torque applications.

The 0-55325-85 has only a few components.  This includes one wire wound resistor mounted above the surface of the board, two diodes, a surface wire connection with an open screw clamp, and five axial electrolytic capacitors.  These are placed in a stack on the board with three capacitors on the bottom and two on the top. The five capacitors are then strapped to the board using a zip tie threaded through two drill holes in the board’s surface.  The board is marked 802289-21A 292 along its bottom surface.

For more detailed information regarding the operation or installation of the 0-55325-85, please consult publications from Reliance.  This includes manuals, series user guides, and product data sheets. As the original equipment manufacturer, Reliance was responsible for providing users with all technical support for this product. Please read and follow all safety guidelines.
