Product Description
The 0-58801 unit is a printed circuit resistor board that Reliance Electric created and manufactured. The 0-58801 resistor board has been discontinued by the original manufacturer, but can still typically be found within AX Control’s stock, along with many other obsolete products that Reliance Electric and other companies have designed and produced.
Since the 0-58801 board is a resistor board, it has many resistors lined up on down the middle of the board. These small resistors and are labeled 1R through 5R. They have metal tabs that are labeled from 1A to 12A, and these tabs have wires connected to them that attach to various spots along the board. On each side of the board, you will find six terminals that are labeled 1 through 12. At the top of the board, there is one large capacitor that is suspended above the board using wires that connect to two metal tabs, one on either side of it. This capacitor has 250 VDC of electric potential within it. To mount the board to wherever is most convenient for you, there are two holes that are symmetrically placed on each side of the board. These holes are located in the middle of the shorter sides of the board. Make sure that you have enough space for the 0-58801 resistor board in the location you are planning on mounting it.
The 0-58801 resistor board weighs about 0.23 lbs. or 0.10 kg. Be aware that this total does not include any of the packaging materials that AX Control uses to furnish the products that we ship out to our customers.
