About the 3FN4032
3FN4032
This device is a part of the FlexPak 3000 Series, as a subcategory of controller units. These controller modules were initially designed and manufactured entirely by Reliance Electric. This module is the 3FN4032 unit, a non-regenerative controller module. This controller is a reliable, flexible, and compact unit, with several FlexPak 3000 standard benefits and features embedded and integrated into the unit.
This unit has a dependable supply of Alternating Current, in order to achieve it’s nominal level of reliability. There is a line frequency input for AC, at a rate of 50 to 60 hertz. There is also a phase insensitive AC line input, outfitted with a semiconductor fuse protection.
The 3FN4032 module is designed with an array of versatile power capabilities for a diverse amount of applications. There is a full wave, fully user controlled 6 pulse power conversion function, designed for smooth and efficient operation and high performance. This model is also capable of handling burst firing of SCRs. The possible current is designed with a 150 percent of a full load current for up to one minute.
The graphical display grants operators a user-friendly quick start menu, which allows for an easy set up and configuration. The available, adjustable parameters for the 3FN4032 unit include speed adjustment, linear acceleration and deceleration, current limit, and I/R compensation.
