Reliance Electric 40FN4032 460 VAC 40 HP 50/60 Hz FlexPak 3000 Drive

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 40FN4032 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 40FN4032
  • SKU: 40FN4032RE
  • Manufacturer: Reliance Electric
  • Series: FlexPak 3000

40FN4032 Technical Specifications

Manufacturer Reliance Electric
Series FlexPak 3000
Part Number 40FN4032
Input Voltage 460 VAC
HP 40 HP
Hz 50/60 Hz

Product Description

The 40FN4032 unit is a DC drive that was designed specifically for the FlexPak 3000 line of drives and related products. This product, along with the FlexPak 3000 product line, was created by the company Reliance Electric. If you are in need of the 40FN4032 DC drive for your facility, then look no further than AX Control. Most of the time, we will have this product in stock despite Reliance Electric no longer producing it. Verify its status in our stock by using our website or contacting us via phone or email.

The 40FN4032 DC drive is classified as a three phase, non-regenerative drive with ratings of 40 HP and 460 VAC. In addition to that, the 40FN4032 DC drive has a full load rated RMS AC line current rating of 63 A. This drive, like all others in the FlexPak 3000 series, has 50/60 Hz. Also, the 40FN4032 DC drive has a chassis style enclosure and is UL, C-UL, and CE listed.

The front of the device is home to the OIM, or the operator interface module. The OIM is comprised of two parts: the display and the keypad. The keypad has numerous buttons that can be used to enter inputs into and control the functions of the display, such as enabling the drive to begin its processes or the four arrow buttons that can be used to select specific things on the display. The display has the capability to show numerous pieces of information that will be relevant to the user, such as “Drive Ready” and “Interlock OK.”

Frequently Asked Questions about 40FN4032

Is the Profibus communication card compatible with the 40FN4032?
The 40FN4032 is comaptible with the Profibus communication card as well as the DeviceNet, ControlNet, and Interbus-S communication cards.
What are some digital signals equipped with the 40FN4032?
The 40FN4032 comes equipped with a variety of digital signals such as a drive running contact output, motor thermostat diagnostic input, and customer interlock diagnostic input.
Are there dynamic braking kits available with the 40FN4032?
The FlexPak 3000 series has multiple dynamic breaking kits available that can be purchased and used with the 40FN4032.
Does AX Control offer a warranty with the 40FN4032?
Yes, AX Control offers a two year warranty with the 40FN4032 and all others drives purchased from us. Please contact us if your 40FN4032 stops functioning and we will send you a new drive, complete all repairs, or grant a full refund.
