Reliance Electric Rockwell FlexPak 3000 50HP Drive.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 50FR4042 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 50FR4042
  • SKU: 50FR4042RE
  • Manufacturer: Reliance Electric
  • Series: FlexPak 3000

50FR4042 Technical Specifications

Manufacturer Reliance Electric
Series FlexPak 3000
Part Number 50FR4042
Input Voltage 460 VAC
HP 50 HP
Hz 50/60 Hz

Product Description

The 50FR4042 unit is a FlexPak 3000 DC drive that was produced by Reliance Electric. Although the 50FR4042 DC drive is not in production with Reliance Electric anymore, AX Control may have this device in stock thanks to our access to surplus Reliance Electric stock. Make sure that we have the 50FR4042 DC drive in stock currently by looking on our website at any time.

The 50FR4042 DC drive is classified as a regenerative drive that can operate at both 230 VAC and 460 VAC. When running at 230 VAC, the VDC armature rating is 240 and the VDC field is 150. In addition to that, the HP rating will be 25, the current rating for the DC armature will be 93 A, the rating for the field current will be 15 A, and the current rating for the RMS AC line will be 80 A. Conversely, the 50FR4042 DC drive running at 460 VAC has a VDC armature rating of 500 and a VDC field rating of 300. The horsepower rating will be doubled at 50, the current rating for the DC armature will be lowered to 86 A, the rating for the field current will be the same at 15 A, and the rating for the RMS AC line will be lowered to 74 A. In addition to that, the 50FR4042 DC drive runs at 50/60 Hz and the short circuit rating is 10,000 A.

The 50FR4042 DC drive weighs approximately 58.00 lbs. or 26.40 kg., without any shipping materials considered.

Frequently Asked Questions about 50FR4042

Does the operator interface unit indicate when the 50FR4042 has faulted?
Yes, the 50FR4042's operator interface unit does indicate when the drive has faulted. When the 50FR4042's motor is in overspeed the operator interface unit displays "overspeed".
What languages does the 50FR4042's operator interface unit display?
The 50FR4042's operator interface unit displays six different languages which are english, spanish, italian, french, german, and alphanumeric code.
Can AX Control repair my 50FR4042?
AX Control technicians are able to complete board level repairs on a variety of devices including the 50FR4042. Once all repairs are complete we will preform a fully function test on your device to make sure all issues are solved.
Can the 50FR4042 be converted to a 230 VAC drive?
Yes, the 50FR4042 can be converted from a 460 VAC drive to a 230 VAC drive using the FlexPak 3000 voltage modification kit.

Repair Services For 50FR4042

Type Lead Time Price Action
Repair Service 1-2 weeks $4371

Our highly skilled technicians can repair your 50FR4042. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
