38ER4060 460V VFD

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 896.02.11 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.02.11
  • SKU: 896.02.11RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.02.11 Technical Specifications

Manufacturer Reliance Electric
Series GV3000
Part Number 896.02.11
Input Voltage 380-460 VAC
Enclosure IP20
Keypad/Display Built-In Keypad
Hz 60Hz
Instruction Manual D2-3426 & D2-3427

Product Description

The 896.02.11 module is a bookshelf AC drive that Reliance Electric was responsible for bringing to the market. The 896.02.11 bookshelf AC drive is part of the GV3000 product line, which is now a legacy series, meaning that its products are no longer being manufactured at all. Even though it is no longer being manufactured by Reliance Electric, the 896.02.11 bookshelf AC drive might possibly still be in stock at this time.

The 896.02.11 model is classified as a “bookshelf” AC drive because it is much thinner than a normal drive. They are pulse-width-modulated drives that are designed to provide general purpose (V/Hz) and vector regulation for many different kinds of applications.

The input for the 896.02.11 bookshelf AC drive has the following ratings: 4.8 kVA, 6 A, and 380 VAC - 460 VAC. The output ratings for the 896.02.11 bookshelf AC drive depends on the regulation mode and the carrier frequency at which the 896.02.11 bookshelf AC drive is running. When in V/Hz regulation mode, this particular drive has the following ratings: 2 kHz = 3.8 A, 4 kHz = 3.8 A, and 8 kHz = 2.8 A. When in Vector regulation mode, this particular drive has the following ratings: 2 kHz = 3.1 A, 4 kHz = 3.1 A, and 8 kHz = 2.8 A. The power loss rating for this drive at full load is 70 W.

Since this drive is smaller in size than a normal drive, it has a smaller weight as well. The 896.02.11 bookshelf AC drive weighs in at 12.00 lbs. or 5.50 kg.

Frequently Asked Questions about 896.02.11

How many input amps does 896.02.11 have?
896.02.11 has 6 input amps.
What are the power loss watts on 896.02.11?
896.02.11 has 70 power loss watts when 896.02.11 is at full load.
Which manual is the best manual for identifying fault codes on 896.02.11?
Manual D2-3426, the software start-up manual for 896.02.11, is the best manual for identifying fault codes on 896.02.11. Table 5.2 in Manual D2-3426 identifies various fault codes on 896.02.11. The manual provides the fault code, a fault description, fault cause, and the corrective action to fix the fault on 896.02.11. For a copy of this manual, send a request for the 896.02.11 manual, Manual D2-3426.
Which terminal is for the common on 896.02.11?
Terminal 9 on 896.02.11 is for the regulator common on 896.02.11. Terminal 25 on 896.02.11 is the +24 VDC common on 896.02.11.
