The 896.03.70 drive is a GV3000 drive manufactured by Reliance Electric; this model operates on 3 HP in V/Hz or Vector regulation. There are two alternate part numbers often associated with the 896.03.70 drive; the more commonly known part number is 3V4460, and the other is the GV3000 catalog number with the number GV3000U-AC006-AF-DBT.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 896.03.70 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.03.70
  • SKU: 896.03.70RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.03.70 Technical Specifications

Part Number 896.03.70
Catalog Number GV3000U-AC006-AF-DBT
US Model Number 3V4460
Series GV3000
Manufacturer Reliance Electric
Instruction Manual D2-3359 & D2-3360
Keypad/Display Built-In Keypad
Enclosure Type 4X/IP54
Phase 3 Phase
Inputs Amps 6.4
Input KVA 5.1
Input Voltage 380-460 VAC
Power Loss Watts (Full Load) 140
Motor Power 2.2 kW
NEMA Rating NEMA 4X/12
HP 3 HP
Hz 50/60Hz

Product Description

Manufactured by Reliance Electric for the GV3000 series, the 896.03.70 drive is specifically an AC power drive. This drive will operate on 3 HP in either Vector or Volts/Hertz regulation; the motor power for this drive, no matter in vector or volts/hertz regulation 2.2 kW at 400 VAC. This specific model is also known as an inverter drive with DC-bus terminals. The 896.03.70 drive has two other part numbers, the most common of the two is 3V4460 with the other being the GV3000 catalog number GV3000U-AC006-AF-DBT. The AF-DBT in the catalog number helps indicate what version the drive is.

When being operated the 896.03.70 drive will operate in a voltage range of 380 to 460 VAC. There are several NEMA ratings typically associated with AC power modules, one is NEMA 1 and the other is NEMA 4X/12, this model has a 4X/12 NEMA enclosure. A NEMA 4X/12 enclosure is not vented but does have a keypad and base gaskets on the drive, the drives with these enclosure types are only rated for indoor environments.

When the 896.03.70 drive is used with its other model number of GV3000U-AC006-AF-DBT it will define a frequency converter through the different characters some examples are enclosure type, the DC-bus terminals, and AC input. There is a nominal inverter current that operates at 2 kHz. There are two current values depending on the regulator type, for vector regulation the value is 5.3 with the V/Hz regulation current value being 5.8.

Frequently Asked Questions about 896.03.70

What is a function loss fault caused by on 896.03.70?
A function loss fault on 896.03.70, fault code "FL," is caused when the function loss input on 896.03.70's control terminal is opened. To correct this fault on 896.03.70, check external interlocks at terminals 16 and 20 on 896.03.70.
What is 896.03.70's speed control response?
896.03.70 has a typical 15Hz speed control response.
What are the manuals for 896.03.70?
The manuals for 896.03.70 are the software and hardware manuals for GV3000 NEMA style drives, including 896.03.70. These manuals are manuals D2-3359 and D2-3360, respectively. For copies of the manuals, send us requests for 896.03.70 manuals.
Can AX Control repair my 896.03.70?
Yes, we'd be happy to repair your 896.03.70. Our team specializes in repair on GV3000 drives and can easily repair your 896.03.70. For a lead time on the repair and a repair quote, contact a sales representative about the 896.03.70 repair.

Reviews For 896.03.70

Internal Review
(5.0)

The 896.03.70 drive is the perfect model if searching for a model with two IP versions which are IP54/IP52. This model is also excellent as it has different values for switching frequencies for max percentages and nominal amps. - AX Control Technician
