The Reliance Electric drive 896.05.31 is a bookshelf drive with a CE or RFI filter, depending on the part number used. There are two alternate part numbers one is 85ET4060, and the other is the GV3000 catalog number GV3000E-AC008-AA-DBU-RFI.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 896.05.31 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.05.31
  • SKU: 896.05.31RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.05.31 Technical Specifications

Part Number 896.05.31
Series GV3000
Manufacturer Reliance Electric
Instruction Manual D2-3426 & D2-3427
Enclosure IP20
Keypad/Display Built-In Keypad
Current Rating 8.5 A
Hz 60 Hz
Input Amps 10
Input KVA 8.0
Input Voltage 380-460 VAC
Motor Power 4 kW in V/Hz Mode or 3 kW in Vector Mode
Phase 3 Phase
Power Loss Watts (Full Load) 150

Product Description

Drive number 896.05.31 is the European stock number for the 85ET4060 GV3000 bookshelf drive. The US model number helps the user in deciding what type of model they should use as there is a full character breakdown of the part number, for example, the 85 in the part number indicates that it has a current rating of 8.5 A. The ET in the part number lets the user know whether or not the drive has a filter, which in this case, the model does have a CE filter. While the 896.05.31 model is the European stock number, there is also another part number used in association with this drive, the GV3000 catalog number of GV3000E-AC008-AA-DBU-RFI is that number.

The GV3000 catalog number is mostly used when needing to describe the drive in depth in the relation to the GV3000 series, for example, the characters at the end of the model number are used to determine what version the drive will be, in this case with the DBU-RFI codes is the DC-bus terminal, RFI filter, braking unit version. The AC008 in the catalog number helps indicate two main things which are the nominal motor power and the nominal inverter current, as this drive can be used in Volts/Hertz or Vector Regulation there are two values for each of these specifications. For drives used in V/Hz regulation, the value is a nominal current of 8.5 with the nominal motor being 4 kW.

All information on the 896.05.31 drive comes from two manuals, one is the D2-3427-3 GV3000/SE Bookshelf Drive Hardware Reference, Installation, and Troubleshooting Manual with the other being GV3000/SE AC General Purpose and Vector Drive Instruction Manual GV3000-UM060K-EN-P.

Frequently Asked Questions about 896.05.31

Where can I get help on installing power wiring on 896.05.31?
The hardware manual for 896.05.31, Manual D2-3427, will help you greatly with installing power wiring on a Reliance 896.05.31. Manual D2-3427 has a chapter in the manual on installing input power wiring and a chapter in the manual on installing output power wiring. For a copy of this manual, request a link to Manual D2-3427 for 896.05.31.
What is the input KVA on 896.05.31?
896.05.31 has 8.0 KVA input.
How many power loss watts does 896.05.31 have?
896.05.31 has 150 power loss watts when 896.05.31 is operating at full load.
What does the "EC" fault code error indicate on 896.05.31?
The "EC" fault code on 896.05.31 is the fault code error for an earth current failure. This fault is caused by an unintentional grounding of the output on 896.05.31. To correct this fault on 896.05.31, check isolation between ground and output terminals. This fault could be caused by leakage or current sensor defects. You may have to replace the sensor on 896.05.31 to correc this fault.

Reviews For 896.05.31

Internal Review
(4.0)

The primary downside of owning the 896.05.31 drive is that there is no communication door which helps with access to the ports inside the drive, as such, all users who need to get inside of the model quickly should find another model that is equipped with a communication door for easy access to the ports. - AX Control Technician

Repair Services For 896.05.31

Type Lead Time Price Action
Repair Service 1-2 weeks $1494

Our highly skilled technicians can repair your 896.05.31. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
