Product Description
Model number 896.07.31 is a bookshelf drive in the GV3000 series, operating on a current rating of 15.0 amperes. The 896.07.31 drive is commonly referred to as the European stock number. The European stock number indicates the power module size and version of the inverter drive of the module. As there is a European stock number there is also a US model number, the US model number of this drive is 150ET4060. The breakdown of this model number is by current rating, drive type, voltage, enclosure rating, and regulator version. The drive type is indicated by the ER in this number; the ER indicates that the bookshelf drive is equipped with a CE filter.
There is a catalog number associated with the 896.07.31 drive. The catalog number is specific to the GV3000 frequency converters. This model's catalog number is GV3000E-AC015-AA-DBU-RFI. The three ending sections of this mode, AA-DBU-RFI, will indicate the inverter version which in this case is equipped with a braking unit, radio frequency interference line filter, and DC-bus terminals. The AC015 at the beginning of the part number is used to indicate the motor power and inverter current. There are two values for the motor power and inverter current due to the different regulators it can be used with. The motor power for the drive in vector mode is 5.5 kW, with the nominal current being 11 A.
For information regarding how to install the 896.07.31 drive, or even troubleshoot it, refer to the D2-3427 GV3000/SE AC Bookshelf Drive Hardware Reference, Installation, and Troubleshooting Manual which be located in the manuals tab above.
