Reliance Electric GV3000 Bookshelf Drive 896.09.11 does not have a CE or RFI filter. This drive can operate on both vector and volts/hertz regulation. The 896.09.11 module has an IP20 enclosure, meaning it is protected against solid objects greater than 12 mm but is not water-tight.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 896.09.11 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 896.09.11
  • SKU: 896.09.11RE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

896.09.11 Technical Specifications

Part Number 896.09.11
US Model Number 300ER4060
Series GV3000
Manufacturer Reliance Electric
Instruction Manual D2-3426 & D2-3427
Enclosure IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
Input Voltage 380-460 VAC
Hz 50/60Hz
Input Amps 38 A
Input KVA 30.2 KVA
Power Loss Watts (Full Load) 470
Motor Power in Vector Mode 11
Inverter Current in V/Hz Mode 30 A

Product Description

GV3000 bookshelf drive 896.09.11 runs on a Volts/Hertz (V/Hz) current rating of 34.0 amperes. The 896.09.11 number is the European stock number for the US model number 300ER4060. The ER within the US model number indicates whether or not the drive has a CE filter; this drive does not. The voltage used during the operation of the drive is in the range of 380 to 460 VAC. The enclosure, which is designated by the 0 following the 4 in the US model number is IP20. IP20 enclosures are not water-tight but will protect the drive against any solid objects larger than twenty millimeters.

There is another part number associated with the 896.09.11 drive which is referred to as the catalog number. The catalog number is GV3000E-AC030-AA-DBU which will indicate the nominal inverter current, the motor power when operating at 400 VAC, and the inverter versions. The last two sections, AA-DBU, indicate the inverter type of this drive, the inverter type is the most basic version with a braking unit and DC-bus terminals. The motor power and nominal current depend on the chosen regulator mode, for example, when the drive is in vector mode the motor power will be 11 kW and the nominal inverter current will be 22 A.

There are three carrier frequencies used for the output current ratings on the 896.09.11 drive, the frequencies are all kHz and the values are 2, 4, and 8 kHz. The two values are nominal amperage and maximum percentage. The maximum percentage for each frequency is 110%. The differing nominal amperages are as follows; 30 A at 2 kHz, 24 A at 4 kHz, and 16.5 A at 8 kHz.

Frequently Asked Questions about 896.09.11

What is the line voltage variation on 896.09.11?
896.09.11 has a -10% to +10% line voltage variation.
What is the overcurrent IET on 896.09.11?
896.09.11 has a 200% load overcurrent IET.
Which manual is best for 896.09.11?
Both manuals listed above are helpful with 896.09.11. Each manual will help you with 896.09.11 in a different way. Manual D2-3426 is the software manual for 896.09.11 and this manual covers starting up 896.09.11, using the keypad on 896.09.11, programming reference, and troubleshooting 896.09.11. Manual D2-3427 is the hardware manual for 896.09.11 and this manual covers a description of 896.09.11, planning before installation of 896.09.11, mounting and grounding 896.09.11, wiring 896.09.11, completing 896.09.11's installation, and troubleshooting 896.09.11. For a copy of either manual, send us a request for the manual you'd like.
What is parameter P.009 on 896.09.11?
Parameter P.009 on 896.09.11 is the terminal strip analog input offset parameter on 896.09.11. This parameters allows correction of any offset in 896.09.11's terminal strip analog input prior to the signal reaching 896.09.11. This parameter is not used on 896.09.11 if the terminal strip analog input is used as vector torque reference on 896.09.11.

Reviews For 896.09.11

Internal Review
(5.0)

The 896.09.11 drive has line input current and branch circuit protection fuses. There are two types of AC-input currents, one with a choke and the other without choke, the fuse for input currents with a choke is 38 amperes, and the fuse for an input current without a choke is 32 amperes. These are the basic amperages and will depend on the line impedance of the drive. - AX Control Tech
