Reliance Electric drive GV3000E-AC030-AA-DBU-RFI is an RFI filter bookshelf drive. The current rating in vector regulation for this model is 22 A. The enclosure for this model can protect the unit from objects 12 mm or larger.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a GV3000E-AC030-AA-DBU-RFI to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: GV3000E-AC030-AA-DBU-RFI
  • SKU: GV3000EAC030AADBURFIRE
  • Manufacturer: Reliance Electric
  • Series: GV3000 Drives

GV3000E-AC030-AA-DBU-RFI Technical Specifications

Part Number GV3000E-AC030-AA-DBU-RFI
US Model Number 300ET4060
European Stock Number 896.09.31
Series GV3000
Manufacturer Reliance Electric
Enclosure IP20
Keypad/Display Built-In Keypad
Phase 3 Phase
Input Voltage 380-460 VAC
Hz 50/60Hz
Inverter Current in Vector Mode 22 A
Input Amps Power Rating 32 A
Output Amps in Vector Mode at 2 kHz 22.0 A
Motor Power in V/Hz Mode 15 A at 400 VAC

About the GV3000E-AC030-AA-DBU-RFI

Bookshelf drive number GV3000E-AC030-AA-DBU-RFI was made by Reliance Electric for their GV3000 series of drives. The current rating on this drive is 30.0 A, denoted by the 30 in the AC030 section.

Two other reference numbers refer to the GV3000E-AC030-AA-DBU-RFI drive, the US model number, and the European stock number. The US model number is the most common number when referring to this drive. The US model number is 300RT4060, which denotes whether or not the model comes with a filter, which in this case is a radio frequency interference (RFI) line filter or a CE filter. The European stock number 896.09.31 indicates the power module size and the components of the drive, which are a previously mentioned filter, a braking resistor circuit, and DC-bus terminals. More information on the components can be found in the GV3000-UM060K-EN-P GV3000/SE AC General Purpose and Vector Drive Instruction Manual and the D2-3427 GV3000/SE AC Bookshelf Drive Hardware Reference, Installation, and Troubleshooting Instruction Manual.

One of the many components of the GV3000E-AC030-AA-DBU-RFI drive is the keypad/display. The keypad/display programs and operates the drive. The display will indicate drive parameters, error codes, and parameter values. There are fourteen LEDs on the keypad, which indicate the operating mode and status of the drive. The drive outputs will also be displayed on the keypad’s display.

This drive can have optional equipment installed; some of these optional equipment types are a ControlNet Network option board, an AutoMax RS-232 Adapter Cable, and more. Refer to the D2-3427 manual Table 2.2 for the optional kits.

Frequently Asked Questions about GV3000E-AC030-AA-DBU-RFI

How many power loss watts does GV3000E-AC030-AA-DBU-RFI have?
GV3000E-AC030-AA-DBU-RFI has 470 power loss watts.
What parameters do you set on GV3000E-AC030-AA-DBU-RFI to establish the maximum motor speed?
To establish the max motor speed on GV3000E-AC030-AA-DBU-RFI, you need to set several parameters. The parameters you should adjust on GV3000E-AC030-AA-DBU-RFI are: parameter P.004- maximum speed, parameters U.001-U.003, and parameters U.005 and U.017- the motor nameplate RPM and motor top speed parameters.
What is the short circuit rating on GV3000E-AC030-AA-DBU-RFI?
GV3000E-AC030-AA-DBU-RFI has a 29 kA short circuit sym RMS rating.
What is the serial number for GV3000E-AC030-AA-DBU-RFI?
The serial number for GV3000E-AC030-AA-DBU-RFI is A/17759.

Reviews For GV3000E-AC030-AA-DBU-RFI

Internal Review
(5.0)

This drive is one of the last bookshelf drives from Reliance Electric; this model comes with a CE or RFI filter and operates on a higher amperage than the other previous models. The GV3000E-AC030-AA-DBU-RFI drive is an excellent purchase due to these features, as well as its ability to be used with several different regulation types. - AX Control Tech
